Malmet WDS1 - Device Specifications

Bedpan / Urinal Bottle and Utensil / Bowl Washer Disinfector (WDS)
Operation, Maintenance and Installation Manual
Issue 16 Page 43 August 22
6.2 Device Specifications
Model WDS
Single Phase
Electrical Rating
Volts
240V
APPROVALS
Phase / Hz
1 ph / 50 Hz
Amps
20 Amps
Heating Elements
Steam Generator
4500W 240V 3 x 6.25A Star
Water tank
4500W 240V 3 x 6.25A Star
Model WDS
Three Phase
Electrical Rating
Volts
415V
Phase / Hz
3 ph / 50 Hz
Amps
20 Amps
Heating Elements
Steam Generator
4500W 240V 3 x 6.25A Star
Water tank
7200W 240V 3 x 10A Star
Heating Element
Contactors
Steam heating element
3 pole 7.5kw
W/Tank heating element
3 pole 7.5kw
ELECTRICAL (Common components)
Element over temperature cut-out
Steam Generator
Capillary bulb thermal cut out
Manual reset 115°c 25A
Water tank
Capillary bulb thermal cut out
Manual reset 100°c 25A
Fuse: Transformer
Cylinder type 5 x 20mm
T 5A H 250Vac Time Delay
Door Actuator
Type LA12 Self-Locking
24VDC
Interlock Micro Switch
SPDT
240VAC 16A
Processor module battery
Coin Cell
CR2032 Lithium 3Volts
PCB HARDWARE
PCB (Printed Circuit Boards)
Display LCD
D134411
Heating switch module
D132213
Control module
D134412
Processor module
D133447
Conductivity sensor
D134418
PC Interface Port
USB Type B
Environment conditions
(Operating)
Location
Indoor Use
Altitude
<2000m
Temperature
+10°C to +25°C
Relative Humidity
+30% to 75%
Mains voltage fluctuations
240+10%
Overvoltage
Category II
Pollution
Degree II
WASH CHAMBER
Loading Configurations
Bedpan Cycle
4 x Urinal Bottles and One (1) of the
following:
2 x Small slipper pans & Lid
2 x Large Slipper pans & Lid
2 x Standard Bedpans & Lid
Urinal Cycle
4 x Urinal bottles Only
Bowl / Utensil
Cycle
2 x Large bowls
3 x Medium bowls
6 x Large kidney dishes
6 x Medium kidney dishes
Assortment of Smaller bowls and kidney
dishes using optional accessory basket.
Chamber Specifications
Material
1.2mm 304 Stainless Steel
Design Life
Minimum of 10,000 Cycles
Usable Volume
100L
Total Volume
115L
WASH SYSTEM
Nozzles and Sprays
Flush nozzles
2 x Rotary Nylon
Tip sprays
2 x WL1/2 120° 1/8 BSP SS
Top sprays
4 x WL1/4 90° 1/8 BSP SS
Bottom sprays
4 x WL1/2 60° 1/8 BSP SS
Urine Bottle sprays
4 x WL1/4 90° 1/8 BSP SS
Cool Down sprays
2 x LW1 120° 1/4 BSP SS
Wash pump
Horizontal multistage
240V 1ph 3.1A
Detergent
Malmet specific (5Lt)
Detergent Concentrate Caustic
Alkaline
ARTG Class 1
Detergent pump
Self-priming peristaltic pump
240V 50Hz
