LEVEL 0
LEVEL 1
SELECT
COMMENTS
(MENU changes to parameters are stored to EEROM)
MENU
BACKLIT
0(OFF) to 12(Max)
HANDS
OFF/ON
Option to disable H/Free Not Yet Available
USEHOT
OFF/ON
Option to Disable Hot Water Filling
BUZZER
ALL ON/OFF
KEYS ON/OFF
HAND ON/OFF
STAT ON/OFF
END ON/OFF
FLT ON/OFF
DISINF
nn
Curr % Level
EMTYCAL
Calibrate – Empty
FULLCAL
Calibrate – Full
EXIT
EXIT
DATE
CURRENT
ddmmmyy
Displays curr Date Only
DAY
dd(Increment 1..31)
MONTH
mm(Increment 1..12)
YEAR
yy(Increment 2010..)
SAVE
EXIT
TIME
CURRENT
hh:mm
Displays curr Time Only
HOUR
hh(Increment 0..23)
MINS
mm(Increments 0..59)
SAVE
EXIT
(Press Enter Toggles ON/OFF)
TEST
RELAYS
OPEN ON/OF
Door Open
CLOS ON/OF
Door Close
COLD ON/OF
Cold Tank Fill
HOT ON/OF
Hot Tank Fill
STEA ON/OF
Steam Tank Fill
DRAIN ON/OF
Drain Solenoid
SPR ON/OF
Cool Spray
DRY ON/OF
Dryer Fan Heater
LAMP ON/OF
Lamp
EXIT
PUMP
URIN ON/OF
Urine Spray
TIP ON/OF
Tip Sprays
TOP ON/OF
Top Sprays
BOTT ON/OF
Bottom Sprays
BEDP ON/OF
Bedpan Sprays
RUN ON/OF
Main Flush Pump On (requires at least one solenoid on and min
water level and door closed)
EXIT
HEATERS
WH1 ON/OFF
Water Heater 1
WH2 ON/OFF
Water Heater 2
SH1 ON/OFF
Steam Heater 1
SH2 ON/OFF
Steam Heater 2
ENAB ON/OFF
Heaters Enable Relay
Note (1) – requires min water and door closed
Note (2) – can only select WH1&WH2 or SH1&SH2
