4.4 Opera Control Box with BOARD 070
Table 19 - Control Box Replacement Components (CBOX 040)
No Qty Description
Manaras-Opera
Part #
1 1 RADIO CONTROL TERM STRIP TSTRIP005
2 1 RESET SEE Table 20
3 2 SINGLE LIMIT SWITCH - LEVER 46 DEG LIMIT023
4 1 STD ELECT. CONTR. BOARD BOARD070M/E
5 1 STD ELECT. POWER BOARD 2 RELAYS BOARD066
6 1 STD SINGLE CUT-OFF SWITCH LIMIT020
7 1 TRANSFO TO 24V SEE Table 20
For technical support, please call 1-800-361-2260 or visit www.manaras.com for more information
Figure 47 - Opera Control Box with BOARD 070M/E
