2 - 11
B - CONTROL POINT IN THE ACCESS PLATFORM
21 - EMERGENCY STOP
22 - INCLINATION CONTACTOR OF THE PLATFORM
23 - RAISE AND LOWER CONTACTOR OF THE EXTENSION ARM
24 - OUTPUTS AND INPUTS CONTACTOR OF THE TELESCOPE
25 - RAISE AND LOWER CONTACTOR OF THE SUPERIOR ARM
26 - TRANSLATION CONTACTOR
27 - LOWER ARM LIFTING AND LOWERING SWITCH
28 - CONTROL SWITCH
29 - CONTACTOR OF SELECTION OF ROTATION
30 - SLOPE LAMP
31 - OVERLOAD LAMP AND VARIATOR DEFECTS
32 - COMMAND BUTTON OF THE SOUND ALARM HORN
33 - ALARM BUZZER
34 - POINTS FOR ATTACHING THE SAFETY HARNESS
NOTE: The terms RIGHT-LEFT-FRONT-REAR apply to a user on the nacelle platform in the transportation
position and looking straight ahead.
