17 - SLOPE SENSOR
- This sensor control the sope of the access platform. When the access
platform is on the max. admissible slope, the alarm sounds (item 33) is
activated discontibuously. The led (item 30) in the access platform,
comes on.
18 - “STATE OF CHARGE OF THE BATTERY” LAMP
- The lamp changes of colors according to the state of the battery
charge:
The red led:
- The charger is on the initial phase of charge.
The yellow led:
- The battery is charged at 80% of charge.
The green led:
- The battery is charged.
19 - SOUND ALARM HORN
- This sound alarm horn is activated when we press the button 32.
