2-35
100 SEC LIFTING PLATFORM EQUIPMENT
1- LIFTING PLATFORM EXTENSION AND RETRACTION
- Push the lifting platform extension locking pedal with your foot.
- Push the extension until the lifting platform has extended to the desired position.
- Do not lean on the lifting platform extension while it is deploying.
- Lower the lifting platform extension locking handle.
2- MAINTENANCE ARM
Use the maintenance arm for any work on the scissors when they are in transport
position.
- Raise the scissors, using the base console, to free the maintenance arm.
- Swivel the maintenance stand to position it.
- Using the base console, instruct the scissors to descend until the maintenance arm is
in contact with the lower scissors axis.
- Switch o the lifting platform using the Emergency Stops.
- Perform the necessary repairs.
1
1
647369 (01/03/2017) 78/100 SEC 2 / 120 SE 2
