2 - 22
I
NDISPOSITION OF THE USER
In the event that the user is taken ill, or is unable to operate the machine,
then the person on the ground can take control of the platform.
Follow the instructions below.
- Set to basket control, position C, using selector 1 (Fig. A).
- Press the "Fail-safe" button 2 (Fig. A).
- Lower the platform using the mast and suspension descent buttons.
Pay attention to any structures or obstacles located below the platform platform.
IN THE EVENT OF ACCIDENT OR BREAKDOWN
Whenever an accident or breakdown occurs which renders the electric control
units inoperable, the machine still has systems for the manual lowering of the
mast and the arm.
- Open the left cowling of the turret.
TO LOWER THE TELESCOPIC MAST:
- Remove the clip (Ref.3, Fig. B).
- Unscrew the valve control knob (Ref.4, Fig. D).
- Pull the control lever manually (Ref.5, Fig. D) to lower the mast.
- Release the control (control lever 5) when the platform platform is in the
desired position.
RESCUE PROCEDURE
B
C
A
1
4
D
5
3
2
C
