29
MATTOC PRO SERVICE MANUAL
4
5
6
Insert compression damper into the
damper leg. Ensure the damper is set in
the unlocked position when installing.
Using the Manitou cassette tool and
torque wrench, tighten down the MC2 at
a torque of 60–80 in lb
[6.8–9.0 N m].
Place the silver spacer onto the MC2
damper, at side facing up.
COMPRESSION DAMPER INSTALL
