MC 70 POWERSHIFT Série 2
HYDRAULIC CIRCUIT
- Type of pump
. Capacity
- Lifting, tilting, attachment circuit
. Flow rate at full speed
. Pressure
- Steering circuit
. Flow rate at full speed
. Pressure
- Filtration
. Return
. Suction
- Hydraulic shock absorber
. Capacities
. Pressure
Gear pump with flow divider
37 cm3
87 L/min
230 Bar
Load control system
145 Bar
10 µ
100 µ
1,4 L
150 Bar
DIMENSIONS PRESSURE TYRE LOAD PRESSURE ON THE CONTACT SURFACE AREA OF THE CONTACT SURFACE
HARD GROUND LIGHT GROUND HARD GROUND LIGHT GROUND
STANDARD
18R19,5 XF Tubeless *PR 7 Bar 1850 kg 3,6 kg/cm2 1,69 kg/cm2 507 cm2 1094 cm2
MICHELIN 7100 kg 4,7 kg/cm2 2,19 kg/cm2 1500 cm2 3236 cm2
Unladen
Laden
OPTION
18R22,5 XF Tubeless *PR 7,5 Bar 1850 kg 2,3 kg/cm2 1,07 kg/cm2 800 cm2 1726 cm2
MICHELIN 7100 kg 4,6 kg/cm2 2,11 kg/cm2 1560 cm2 3365 cm2
445/65R19,5 XZY TL 165K 7,5 Bar 1850 kg 4,6 kg/cm2 kg/cm2 400 cm2 cm2
MICHELIN 7100 kg 7,1 kg/cm2 kg/cm2 1007 cm2 cm2
Unladen
Laden
Unladen
Laden
DIMENSIONS PRESSURE TYRE LOAD PRESSURE ON THE CONTACT SURFACE AREA OF THE CONTACT SURFACE
HARD GROUND LIGHT GROUND HARD GROUND LIGHT GROUND
OPTION
285/70 R19,5 XZY 140/137L 6,5 Bar 3050 kg 6,1 kg/cm2 kg/cm2 499 cm2 cm2
MICHELIN 1300 kg 9,3 kg/cm2 kg/cm2 140 cm2 cm2
Unladen
Laden
STANDARD
9,5R19,5 Tubeless XZY 134/131K 8 Bar 3050 kg 7,3 kg/cm2 kg/cm2 416 cm2 cm2
MICHELIN 1300 kg 7,2 kg/cm2 kg/cm2 180 cm2 cm2
Unladen
Laden
FRONT TYRES
R
EAR TYRES
CHARACTERISTICS
