DESCRIPTION
1 - DRIVER'S SEAT
2 - SAFETY BELT
3 - SIGNAL LAMP PANEL
4 - FUEL LEVEL AND HOURMETER
5 - SWITCH PANEL
6 - LIGHT SWITCH, HORN AND INDICATOR SWITCH
7 - IGNITION SWITCH
8 - BRAKING OIL TANK
9 - FUSES
10 - ROOF LIGHT
11 - WINDSCREEN WASHER TANK
12 - ACCELERATOR PEDAL
13 - SERVICE BRAKE PEDAL
14 - TRANSMISSION CUT-OFF PEDAL (INCHING)
15 - FORWARD/REVERSE LEVER AND SPEED SELECTOR
16 - PARKING BRAKE LEVER
17 - HYDRAULIC CONTROLS
18 - CAB HEATER CONTROL
19 - HEATING VENTS
20 - DOORS LOCKS
21 - DOORS UNLOCKING BUTTONS
22 - DOCUMENT HOLDER
23 - DOCUMENT HOLDER NET
24 - FRONT LIGHTS (NOT ILLUSTRATED)
25 - REAR LIGHTS (NOT ILLUSTRATED)
26 - ADJUSTMENT HANDLE OF THE STEERING WHEEL
NOTE : All the terms such as : RIGHT, LEFT, FRONT, REAR are meant for an observer seated on driver's seat and looking in
front of him.
1 - D
RIVER'
S SEAT
DESIGNED FOR MAXIMUM COMFORT, THIS SEAT CAN BE ADJUSTED AS FOLLOWS.
LONGITUDINAL ADJUSTMENT
- Pull the locking lever 1 upwards.
- Slide the seat to the required position.
- Release the lever and ensure it returns to the lock position.
SEAT SUSPENSION ADJUSTMENT
- Pull and lift up the locking lever 2 so as to place it into one of these five positions.
Position A : Light-weight driver (50 kg).
Position B : Intermediate.
Position C : Middle-weight driver.
Position D : Intermediate.
Position E : Heavy-weight driver (120 kg).
ANGLE ADJUSTMENT OF THE BACK-REST
- Pull the locking lever 3 backwards.
- Tilt the back-rest into one of the three possible positions.
- Release the locking lever and ensure it returns to the lock position.
ANGLE ADJUSTMENT OF THE WHOLE SEAT
- Lift up the locking lever 4.
- Tilt the seat forwards or backwards.
- Release the lever and ensure it returns to the lock position.
A
B
C
D
E
1
2
4
3
