2 - 37
10 - ROOF LIGHT
11 - W
INDSCREEN WASHER TANK
See chapter : B - EVERY 50 HOURS SERVICE in paragraph : 3 - MAINTENANCE.
12 - ACCELERATOR PEDAL
When idling, the transmission is automatically cut.
- As soon as you accelerate, the transmission is switched on again.
- When you release the accelerator pedal, the transmission remains on until the engine falls to idling speed.
13 - SERVICE BRAKE PEDAL
The pedal acts on the front wheels by means of a hydraulic brake system enabling the slowing down and stopping of the lift
truck.
14 - TRANSMISSION CUT-OFF PEDAL (INCHING)
This pedal is used to gradually cut transmission, making it easier to use a slow approach for careful handling jobs.
- When you press the transmission cut-off pedal, you first gradually cut transmission and then use the service brake pedal to
stop the machine.
15 - DIFFERENTIAL LOCK PUSH BUTTON
The differential lock allows the main wheels to turn at the same speed whatever the ground condition. In order to engage it, fully
press the push button.
- Maintain this position during the time required for locking. To interrupt its use, simply remove the foot from the top of the push
button which returns to its initial position automatically.
When the differential lock is engaged, always drive in straight line and in first gear.
