2 - 44
1 - REVOLVING LIGHT
The revolving light is dismountable to make it possible, for example, to reduce the
bulkiness of the lift truck or to avoid being stolen.
- Loosen nut 1 and remove the revolving light.
- Protect mounting 2 with cap 3.
2 - REVERSE BUZZER ALARM
3 - BATTERY CUT-OFF
4 - DIGICODE ANTI-THEFT SYSTEM
5 - ADAPTATION 4TH DISTRIBUTOR ELEMENT
LEVER A : Intended for controlling a additional equipment.
DESCRIPTION AND USE OF ELECTRIC AND HYDRAULIC OPTIONS
1
2
3
A
