Manitou MC 70 Turbo POWERSHIFT Serie 3-E3 User Manual

3-15
A = ADJUST, C = CHECK, G = GREASE, N = CLEAN,
P = BLEED, R = REPLACE, V = DRAIN
PAGE
(1)
DAILY OR EVERY 10
HOURS SERVICE
EVERY 50 HOURS
SERVICE
EVERY 250 HOURS
SERVICE
EVERY 500 HOURS
SERVICE OR 6
MONTHS
EVERY 1000 HOURS
SERVICE OR 1 YEAR
EVERY 2000 HOURS
SERVICE OR 2 YEARS
EVERY 4000 HOURS
SERVICE
OCCASIONALLY
BRAKE
Brake oil level
3-25 C C <<< <<< <<< <<< <<<
Parking brake 3-31 C/A C/A <<< <<< <<< <<<
Parking brake lever mechanism 3-38 G G <<< <<< <<<
Brake oil V** <<< <<<
Brake system P** <<< <<<
Brake system pressure C** <<< <<<
Brake A** <<< <<<
STEERING
Steering
C** <<<
Steering swivel joints C**
CAB
Windscreen washer liquid level
3-25 C C <<< <<< <<< <<< <<<
Cab door 3-26 G G <<< <<< <<< <<< <<<
Cab ventilation filter (OPTION Air conditioning) 3-26/31 R N R <<< <<< <<< <<<
Cab ventilation filters 3-38 N N <<< <<< <<<
Seat belt 3-44 C <<< <<<
Condition of the rear view mirrors C** <<< <<<
Structure C** <<< <<<
Air conditioning (OPTION) 3-47 N/C <<<
Raising the overhead guard or the cab 3-50 XXX
ELECTRICITY
Condition of wiring harness and cables
C** <<< <<<
Lights and signals C** <<< <<<
Warning indicators C** <<< <<<
Front headlights 3-51 A
FRONT AXLE
Front axle differential oil level
3-32 C C <<< <<< <<< <<<
Front wheels reducers oil level 3-32 C C <<< <<< <<< <<<
Front axle differential oil 3-38 V V <<< <<< <<<
Front axle cooling circuit filter 3-39 R R <<< <<< <<<
Front wheels reducers oil 3-44 V V <<< <<<
Wear of front axle brake discs C**
Front wheels reducers clearance C**
REAR AXLE MC 30 Turbo Série 3-E3
Swivel pins 3-26 G G <<< <<< <<< <<< <<<
Steering cylinder head axle 3-26 G G <<< <<< <<< <<< <<<
Rear axle oscillation 3-26 G G <<< <<< <<< G/C** <<<
Rear axle C**
REAR AXLE M 26-2 Turbo Série 3-E3 M 30-2 Turbo Série 3-E3
Swivel pins 3-27 G G <<< <<< <<< <<< <<<
Steering cylinder foot axles 3-27 G G <<< <<< <<< <<< <<<
Rear axle oscillation 3-27 G G <<< <<< <<< G/C** <<<
Rear axle C**
REAR AXLE M 26-4 Turbo Série 3-E3 M 30-4 Turbo Série 3-E3 M 40-4Turbo Série 3-E3 M 50-4 Turbo Série 3-E3
Rear wheels reducers pivots 3-27 G G <<< <<< <<< <<< G/C**
Rear axle oscillation 3-27 G G <<< <<< <<< G/C** <<<
Rear axle differential oil level 3-32 C C <<< <<< <<< <<<
Rear wheels reducers oil level 3-32 C C <<< <<< <<< <<<
Rear axle differential oil 3-44 V V <<< <<<
Rear wheels reducers oil 3-45 V V <<< <<<
Rear wheels reducers universal joint C**
Rear wheels reducers clearance C**
REAR AXLE MC 40/50 Turbo POWERSHIFT Série 3-E3 MC 60/70 Turbo POWERSHIFT Série 3-E3
Swivel pins 3-28 G G <<< <<< <<< <<< <<<
Rear axle oscillation 3-28 G G <<< <<< <<< G/C** <<<
Rear axle C**
CHASSIS
Structure
C** <<< <<<
Bearings and articulation rings C** <<<
ATTACHMENTS
Forks wear
C** C** <<< <<< <<<
Attachment carriage C** <<< <<<
Condition of attachments C** <<< <<<
LIFT TRUCK
Tow the lift truck
3-52 XXX
Sling the lift truck 3-52 XXX
Transport the lift truck on a platform 3-53 XXX
647003 EN (03/01/2012)
