Part Number STH025 8/12 129
The following are the procedures for completing each step of the Freeze Cycle Refrigeration System Operational
Analysis Tables. Each procedure must be performed exactly for the table to work correctly.
Final Analysis
Enter total number of boxes
checked in each column.
Reference “Final Analysis - Self-
contained Air, Water & Remote
Condenser Models” on page 152
Harvest Valve
Leaking
Low On Charge
-Or-
TXV Starving
TXV Flooding Compressor
SINGLE EVAPORATOR, SINGLE EXPANSION VALVE
SELF CONTAINED AIR, WATER & REMOTE CONDENSER
Operational Analysis 1 2 3 4
