130 Part Number STH025 8/12
SINGLE EVAPORATOR, DUAL EXPANSION VALVE
SELF CONTAINED AIR, WATER & REMOTE CONDENSER
Operational Analysis 1 2 3 4
Ice Production
Air-Temperature Entering Condenser_____________
Water Temperature Entering Ice Machine_________
Published 24 hour ice production________________
Calculated (actual) ice production_______________
NOTE: The ice machine is operating properly if the ice fill patterns is normal and ice
production is within 10% of charted capacity.
Installation and Water
System
All installation and water related problems must be corrected before proceeding with table.
Ice Formation Pattern
Top or 1 Side_________
Bottom or 1 Side_________
Ice formation is extremely
thin on outlet of
evaporator
-or-
No ice formation on one
side or Top or Bottom of
evaporator
Ice formation is
extremely thin on outlet
of one side or Top or
Bottom of evaporator
-or-
No ice formation on
entire evaporator
Ice formation normal
-or-
Ice formation is
extremely thin at inlet of
one side or Top or
Bottom of evaporatorr
-or-
No ice formation on
entire evaporator
Ice formation normal
-or-
No ice formation on
entire evaporator
To Next Page
