Installation Instructions Section 2
2-2
Part Number 020003315 1/11
FRP-250 Footprint
Minimum Area
for Cutout
Maximum Area
for Cutout
Flav’R-Pic
Maximum Minimum
ABCD
250* 26.00"
(66.0 cm)
17.81"
(45.2 cm)
4.00"
(20.30 cm)
24.00"
(61.00 cm)
Cutting the countertop may decrease its strength.
Counter must be braced to support the dispenser
countertop weight plus ice storage capacity and
weight of icemaker, if applicable.
