Manitowoc Grove RT530E-2 Product Guide

15
RT530E-2
Load charts • Traglasten • Capacités de levage
Capacidades • Capacità • Diagramas de carga
85 %
RT530E-2
Radius m 8,8 12,2 15,2 18,3 21,3 24,4 27,4 29,0 Radius m
3,0 16,125 15,000 14,075 3,0
3,5 12,275 12,125 11,575 3,5
4,0 9,760 9,630 9,585 9,295 4,0
4,5 7,990 7,890 7,865 7,870 7,665 4,5
5,0 6,690 6,605 6,600 6,615 6,695 6,440 5,0
6,0 4,900 4,845 4,855 4,890 5,010 5,055 4,885 6,0
7,0 3,685 3,710 3,760 3,850 3,945 3,925 3,865 7,0
8,0 2,845 2,890 2,960 3,030 3,110 3,190 3,150 8,0
9,0 2,195 2,250 2,325 2,385 2,455 2,530 2,570 9,0
10,0 1,685 1,755 1,835 1,885 1,945 2,005 2,040 10,0
12,0 1,040 1,130 1,160 1,200 1,245 1,270 12,0
14,0 0,645 0,665 0,690 0,725 0,745 14,0
A6-829-100470
3,8 t8,8 - 29,0 m 50 %
360˚
DIN/ISO
RT530E-2
3,8 t8,8 - 29,0 m 0 %
360˚
DIN/ISO
RT530E-2
Radius m 8,8 12,2 15,2 18,3 21,3 24,4 27,4 29,0 Radius m
3,0 27,000 21,750 20,400 3,0
3,5 24,200 21,750 20,375 3,5
4,0 22,050 20,325 18,750 16,775 4,0
4,5 18,550 17,050 15,875 14,875 11,250 4,5
5,0 15,700 14,600 13,700 12,925 10,600 9,525 5,0
6,0 11,200 11,150 10,625 10,100 9,650 8,580 7,375 6,0
7,0 8,405 8,445 8,190 7,855 7,475 6,780 6,395 7,0
8,0 6,595 6,645 6,725 6,530 6,295 6,070 5,900 8,0
9,0 5,315 5,370 5,455 5,520 5,335 5,155 5,070 9,0
10,0 4,345 4,420 4,510 4,465 4,565 4,425 4,355 10,0
12,0 3,100 3,195 3,230 3,275 3,320 3,275 12,0
14,0 2,320 2,345 2,375 2,410 2,430 14,0
16,0 1,690 1,715 1,775 1,760 1,775 16,0
18,0 1,240 1,255 1,275 1,285 18,0
20,0 0,885 0,895 0,905 20,0
22,0 0,580 0,595 0,600 22,0
Radius m 8,8 12,2 15,2 18,3 21,3 24,4 27,4 29,0 Radius m
3,0 14,375 13,125 12,100 3,0
3,5 11,625 10,850 10,125 3,5
4,0 9,655 9,165 8,620 8,105 4,0
4,5 8,155 7,820 7,435 7,035 6,660 4,5
5,0 6,895 6,750 6,490 6,165 5,860 5,570 5,0
6,0 4,990 4,945 4,970 4,835 4,620 4,415 4,225 6,0
7,0 3,715 3,750 3,810 3,710 3,560 3,415 3,340 7,0
8,0 2,845 2,890 2,960 3,010 2,900 2,785 2,730 8,0
9,0 2,195 2,250 2,325 2,385 2,375 2,285 2,240 9,0
10,0 1,685 1,755 1,835 1,885 1,930 1,875 1,835 10,0
12,0 1,040 1,130 1,160 1,200 1,220 1,205 12,0
14,0 0,645 0,665 0,690 0,725 0,730 14,0
A6-829-100582B
85 %
RT530E-2
Radius m 8,8 12,2 15,2 18,3 21,3 24,4 27,4 29,0 Radius m
3,0 27,200 21,750 20,400 3,0
3,5 25,075 21,750 20,375 3,5
4,0 22,350 21,025 19,525 16,775 4,0
4,5 18,725 18,600 17,825 16,350 12,425 4,5
5,0 15,125 15,025 15,000 14,525 12,425 9,525 5,0
6,0 10,725 10,650 10,675 10,700 10,750 9,525 7,710 6,0
7,0 8,085 8,115 8,175 8,280 8,395 7,575 7,030 7,0
8,0 6,390 6,430 6,495 6,575 6,665 6,760 6,665 8,0
9,0 5,190 5,235 5,305 5,370 5,440 5,515 5,560 9,0
10,0 4,275 4,340 4,420 4,470 4,525 4,590 4,620 10,0
12,0 3,100 3,185 3,215 3,255 3,295 3,320 12,0
14,0 2,320 2,345 2,375 2,410 2,430 14,0
16,0 1,690 1,715 1,735 1,760 1,775 16,0
18,0 1,240 1,255 1,275 1,285 18,0
20,0 0,885 0,895 0,905 20,0
22,0 0,580 0,595 0,600 22,0
A6-829-100469A
A6-829-100691
Telescopic boom • Teleskopausleger • Flèche principale • Pluma telescópica • Braccio telescopico •Lança telescópica
