Manitowoc Grove RT530E-2 - Page 16

3,8 t8,8 - 18,3 m 20,5x25 / 0 Kph
360˚
DIN/ISO
RT530E-2
85 %
RT530E-2
Radius m 8,8 12,2 15,2 18,3 Radius m
3,0 11,550 10,575 9,340 3,0
3,5 9,445 8,825 8,190 3,5
4,0 7,875 7,450 7,010 4,0
4,5 6,470 6,370 6,065 5,705 4,5
5,0 5,335 5,350 5,270 5,000 5,0
6,0 3,660 3,675 3,685 3,695 6,0
7,0 2,650 2,660 2,665 7,0
8,0 1,980 1,990 2,000 8,0
9,0 1,495 1,505 1,515 9,0
10,0 1,125 1,135 1,145 10,0
12,0 0,610 0,615 12,0
360 °
Radius m 8,8 12,2 15,2 18,3 Radius m
3,0 11,575 11,575 7,460 3,0
3,5 10,175 10,025 7,460 3,5
4,0 8,850 8,850 7,460 4,0
4,5 7,590 7,590 7,460 7,460 4,5
5,0 6,305 6,305 6,305 6,305 5,0
6,0 4,405 4,405 4,405 4,405 6,0
7,0 3,240 3,240 3,240 7,0
8,0 2,485 2,485 2,485 8,0
9,0 1,930 1,930 1,930 9,0
10,0 1,510 1,510 1,510 10,0
12,0 0,915 0,915 12,0
14,0 0,510 14,0
A6-829-100565B
A6-829-100474A
0° (+/- 6°)
Radius m 8,8 12,2 15,2 18,3 Radius m
3,0 13,650 12,025 7,460 3,0
3,5 12,425 10,025 7,460 3,5
4,0 11,225 10,025 7,460 4,0
4,5 10,175 10,025 7,460 7,460 4,5
5,0 9,225 9,225 7,460 7,460 5,0
6,0 7,610 7,610 7,460 7,460 6,0
7,0 6,005 6,005 6,005 7,0
8,0 5,125 5,125 5,125 8,0
9,0 4,260 4,260 4,260 9,0
10,0 3,535 3,535 3,535 10,0
12,0 2,505 2,505 12,0
14,0 1,705 14,0
16,0 1,210 16,0
A6-829-100473A
RT530E-2
16
Load charts • Traglasten • Capacités de levage
Capacidades • Capacità • Diagramas de carga
Telescopic boom • Teleskopausleger • Flèche principale • Pluma telescópica • Braccio telescopico • Lança telescópica
