Manitowoc Grove RT530E-2 - Page 17

RT530E-2
17
Load charts • Traglasten • Capacités de levage
Capacidades • Capacità • Diagramas de carga
3,8 t8,8 - 18,3 m 4,0 km/h
0°
DIN/ISO
RT530E-2
Radius m 8,8 12,2 15,2 18,3 Radius m
3,0 11,725 11,725 8,275 3,0
3,5 10,500 10,500 8,275 3,5
4,0 9,385 9,385 8,275 4,0
4,5 8,415 8,415 8,275 6,050 4,5
5,0 7,565 7,565 7,565 6,050 5,0
6,0 6,190 6,190 6,190 6,050 6,0
7,0 4,945 4,955 4,965 7,0
8,0 3,920 3,930 3,935 8,0
9,0 3,170 3,180 3,185 9,0
10,0 2,600 2,610 2,615 10,0
12,0 1,795 1,800 12,0
14,0 1,250 14,0
16,0 0,885 16,0
A6-829-100566C
85 %
RT530E-2
Radius m 8,8 12,2 15,2 18,3 Radius m
3,0 11,725 11,725 8,275 3,0
3,5 10,500 10,500 8,275 3,5
4,0 9,385 9,385 8,275 4,0
4,5 8,415 8,415 8,275 6,050 4,5
5,0 7,565 7,565 7,565 6,050 5,0
6,0 6,190 6,190 6,190 6,050 6,0
7,0 5,180 5,180 5,180 7,0
8,0 4,430 4,430 4,430 8,0
9,0 3,820 3,820 3,820 9,0
10,0 3,315 3,315 3,315 10,0
12,0 2,505 2,505 12,0
14,0 1,265 14,0
16,0 0,885 16,0
A6-829-100475A
Telescopic boom • Teleskopausleger • Flèche principale • Pluma telescópica • Braccio telescopico • Lança telescópica
