Part Number: 000015431 Rev01 5/19 35

Additional Refrigerant Charge For 51' to 100'

Line Sets

Ice

Machine

Condenser

Additional Amount of

Refrigerant To Be Added

To Nameplate Charge

IF0600C

CVDF0600

1.5 lbs

680 gIBF0620C

IBF0820C

CVDF0900

4 lbs

1814 gIF0900C

IBT1020C

CVDT1200

2 lbs

907 g

IT1200C

2 lbs

907 g

IF1400C CVDF1400

2 lbs

907 g

IF1800C CVDF1800

2 lbs

907 g

IF2100C CVDF2100

4 lbs

1814 g
