Part Number: 000015431 Rev01 5/19 121
SYMPTOM #3 QUIETQUBE® MODELS WITH CVD CONDENSING UNITS
Ice Machine Will Not Harvest - Freeze Cycle Is Normal and Ice Cubes Are Not Melted After Harvest
START
Is the Harvest Valve(s)
Energized?
Refer to Sequence of Operation
& Wiring Diagram
Note: All pressure readings are
taken from the Liquid & Suction
Shut-off Valves or access ports
at the ice machine head section.
Are the Harvest
Pressures normal?
Is the ice machine
installed correctly?
Correct the
Installation
YES
YES
YES
NO
NO
NO
ICE MACHINE WILL NOT HARVEST - FREEZE CYCLE NORMAL, CUBES ARE NOT MELTED
To Next Page
