Manitowoc Indigo NXT Series Technician's Handbook

“Part Number: 000015431 Rev01 5/19” 71
HOME SCREEN ICON DESCRIPTIONS
Icon Description
Home Screen Pressing this icon at any time will return the
display to the home screen.
State of ice Machine is the center portion of the
screen which displays the current condition of
the ice machine - Making ice, bin full, program
mode or machine off
Alert Alert icon with number of messages. Pressing
this icon will display the alert log which will
allow viewing and resetting of alerts
Message Message icon with umber of messages. Pressing
this icon will display the routine maintenance
reminder screen which will allow viewing and
resetting of the reminder
Menu Menu icon will take you to the main menu.
Note: This icon changes to a lock if the
touchscreen lock has been selected.
Information Information icon provides model and serial
number, installation date and other information
specific to the ice machine.
Service Locator Provides contact information for your local
service support - Default is the Manitowoc Ice
website service locator
Lock/Unlock Indicates if screen is locked or unlocked.
The icon is only visible when the screen is
locked.
LuminIce Only visible when a LuminIce II accessory is
connected.
Blue S - Normal operation
Red S - Replace bulb
Red/Blue alternating - Incorrect bulb installed
3
3
i
S

Manitowoc Indigo NXT Series Specifications

General

Model	Indigo NXT Series
Ice Production	Varies by model
Ice Storage	Varies by model
Energy Efficiency	Energy Star certified models available
Refrigerant	R290 (varies by model)
Cooling System	Air-cooled or water-cooled (varies by model)
Condenser Type	Air-cooled, Water-cooled, or Remote
Touch Display	Yes, with intuitive interface
Control	Cleaning Alerts
Features	Self-cleaning, remote monitoring, energy-saving modes
Power Supply	Varies by model (typically 115V or 208-230V)
Dimensions (H x W x D)	Varies by model
Weight	Varies by model
