FIGURE 9
Engine Components – Cummins QSG12 Engine
Item Description Required Service
1 Dipstick
Service according to the
engine manufacturer’s
instructions.
2 Fuel Filter
3 Quick-Drain Valve
4A Fuel Filter
4B Fuel Filter (see NOTE)
5 Oil Fill Caps
6 Oil Filter
7 Diesel Particulate Filter
NOTE Inspect fuel filter (4B) daily while the
engine is running. Change the filter
element only when the fuel level
reaches and remains at the top of
the black band on the filter cover.
