Manitowoc MLC300 Guide

Lubrication Guide MLC300
F2280-18
Published 07-21-21
Upper and Lower Lubrication — Identification
NOTE 1 Inspect the crane daily for leaks. If a leak is
found, determine the cause, take corrective
action, and refill the applicable component with
proper fluid.
NOTE 2 Fill through the fitting in the base of the reservoir
using a hand-operated grease gun or pump.
Refill the reservoir when the grease reaches the
MIN mark. Fill the reservoir to the MAX mark.
The crawlers and turntable bearing are greased
automatically by electric pumps when the
ignition switch is on.
NOTE 3 Drain any accumulated water from the fuel and
hydraulic tanks at the start of each work day.
Crack open the quick-drain valve using the
quick-drain drainer assembly. Disconnect the
quick-drain drainer assembly as soon as water
stops draining and a steady stream of fuel or
hydraulic oil appears.
NOTE 4 Check the coolant level when the coolant is
cold.
Item Description Required Service
Prior to Use When the Crane is Assembled
A1 Carbody Jack Connecting Pin (1 fitting, top and
bottom of each pin, 4 places) (Lowerworks
Jacking Option)
Grease each fitting.
Every 8 Hours of Operation or Daily (whichever comes first)
(see NOTE 1)
D1 Ring Gear Check for proper lubrication. Coat with open gear oil if needed.
D2 Grease Pump Reservoirs (1 for turntable bearing
and 1 optional for each crawler)
Check reservoir level. Fill to the proper level with approved
grease (see NOTE 2).
D3 Air Cleaner Service Indicator Check. Replace element when indicated.
D4 Coolant Expansion Surge Tank Sight Gauge Check the level, should be at full cold mark (see NOTE 4).
D5 Coolant Expansion Surge Tank Fill Cap Fill to the proper level with coolant.
D6 Fuel Tank Quick-Drain Valve Drain water (see NOTE 3).
D7 Fuel Tank Level Gauge Check level, fill to high mark on gauge.
D8 Fuel Tank Fill Cap Fill to the proper level with fuel oil.
D9 Hydraulic Tank Quick-Drain Valve Drain water (see NOTE 3).
D10 Engine (see Figure 9
and Figure 10) Service according to the engine manufacturer’s instructions.
D11 Windshield Washer Reservoir Check level. Fill to base of opening with windshield washer
fluid.
D12 VPC Gear Rack (both sides of crane) Check for proper lubrication. Coat with open gear oil if needed.
Clean all debris from roller path.
Item D13 and D14 Not Used
FOR REFERENCE
ONLY
