Manitowoc RNS0308 User Manual

184 Part Number 000007661 11/16
RF1200W
WATERCOOLED
Characteristics vary depending on operating conditions.
ICE PRODUCTION
Model Air Temperature
Water
Temperature
24 hour
Ice Production
RF1200W
70°F/50°F
21°C/10°C
1204 lbs
546 kgs
90°F/70°F
32°C/21°C
1004 lbs
455 kgs
RFS1200W
70°F/50°F
21°C/10°C
1339 lbs
607 kgs
90°F/70°F
32°C/21°C
1128 lbs
512 kgs
OPERATING PRESSURES PSIG & kPa
Air Temperature
Around Ice
Machine
°F/°C
Freeze Cycle
Discharge
Pressure
Suction
Pressure
70°F PSIG
21°C kPa
245-255
1689-1758
29-31
200-214
90°F PSIG
32°C kPa
270-280
1862-1930
29-35
200-241
110°F PSIG
43°C kPa
275-290
1896-2000
30-36
207-248
Condenser Water Consumption @ 90°F/70°F 32°C/21°C
RF1200W
103 Gallons/100 lbs. of Ice
390 Liters/45 kgs. of Ice
RFS1200W
118 Gallons/100 lbs. of Ice
447 Liters/45 kgs. of Ice
