Part Number 000007661 11/16 265
RF1200/RFS1200 AIRCOOLED
1
2
3
4
5
6
7
8
TUBING DIAGRAM LEGEND
1 Compressor
2 Condenser
3 Liquid Line Drier
4 Liquid Line Solenoid Valve
5 Suction Accumulator
6 Thermostatic Expansion Valve
7 Liquid Accumulator
8 Evaporator
