Part Number 000007661 11/16 277
RNS0308
1
2
3
4
5
6
TUBING DIAGRAM LEGEND
1 Compressor
2 Condenser (air or water cooled)
3 Liquid Line Drier
4 Heat Exchanger
5 Automatic Expansion Valve
6 Evaporator
