Manitowoc RNS0308 - Nugget Models; Rn0244;Rns0244;Rn0385;Rns0385

276 Part Number 000007661 11/16
Nugget Models
RN0244/RNS0244/RN0385/RNS0385
Air & Water-cooled
1
2
3
4
5
6
TUBING DIAGRAM LEGEND
1 Compressor
2 Condenser (air or water cooled)
3 Liquid Line Drier
4 Heat Exchanger
5 Capillary Tube
6 Evaporator
