Step 2 Time delay cycle normal light operation

The bin fills with ice, the Low Bin light de-energizes and

the Time delay light energizes. The compressor and

gear motor immediately turn off and the condenser fan

continues to run for 10 minutes before turning off. When

the time delay ends and the Low bin light energizes the

ice machine will restart.

PURGE (Y)

WER (G)

W BIN (G)

GER ON (G)

REFRIG ON (G)

CLEANING (Y)

SERVICE (R)

AMPS (R)

HI PRESS (R)

PRESS (R)

DRAIN CL

OG (R)

TIME DELA

Y (Y)

LO WATER (R)

CPU (G)

HI WATER (R)

Step 3 Purge cycle normal light operation

After 1 to 2 hours of ice making the control board will

initiate a purge cycle. The compressor de-energizes and

the gear motor and condenser fan motor continue to run.

After the purge cycle is complete the ice machine starts

without a time delay period.
