Part Number 8001119 10/19 231
QM45/Q130 Tubing Schematic
SV3024
HEAT
EXCHANGER
STRAINER
COMPRESSOR
DRIER
EVAPORATOR
HOT GAS
SOLENOID
AIR OR WATER
CONDENSER
EXPANSION
VALVE
RECEIVER (Q130
WATER COOLED ONLY)
