92 Part Number 8001119 10/19
QM20/QM30
Routine adjustments and maintenance procedures
outlined in this manual are not covered by the
warranty.
Water Inlet Valve
The water inlet valve energizes in the harvest cycle.
The water level will rise and flow out the overflow tube
and down the drain. Verify the overflow tube is in place
in the water trough. The water level is not adjustable.
ATTACHMENT
POINT
OVERFLOW
TUBE
SV3019
