WATER SUPPLY AND DRAIN LINE SIZING/
CONNECTIONS
QM45/Q130/Q170/Q210/Q270
Tubing Size Up to
Ice Machine
Fitting
3/8" (9.5 mm) min.
inside diameter
3/8" (9.5 mm) min.
inside diameter
3/8" (9.5 mm) min.
inside diameter
1/2" (12.7 mm)
min. inside
diameter
Ice Machine
Fitting
3/8" Female
Pipe Thread
3/8" Female
Pipe Thread
3/8" Female
Pipe Thread
1/2" Female
Pipe Thread
Water
Pressure
20 psi (1.38 bar) min.
80 psi (5.5 bar) max.
20 psi (1.38 bar) min.
150 psi (10.3 bar) max.
— —
Water
Temperature
33°F (0.6°C) min.
90°F (32.2°C) max.
33°F (0.6°C) min.
90°F (32.2°C) max.
— —
Location
Ice Making
Water Inlet
Condenser
Water Inlet
Condenser
Water Drain
Bin Drain
