62 Part Number 8001119 10/19
Step 6 Remove parts for cleaning.
A. Remove the Overflow Tube
• To remove the tube, lift it up while using a slight
back and forth motion to loosen it from the drain
hole.
When installing the tube, be sure it is completely
inserted into the drain hole to prevent water leakage
during normal operation.
DRAIN
HOLE
OVERFLOW
TUBE
Removing the Overflow Tube
B. Remove the Vinyl Hose
• Disconnect the water pump discharge hose from
the distribution tube and water pump.
To Next Page
