Manitowoc SM050 User Manual

72 Part Number 8001119 10/19
SUMP DRAIN OVERFLOW TUBE
1. Remove clamp.
2. Pull down to remove overflow tube and tubing as
an assembly. The sump trough water will drain
into the bin.
3. Remove overflow tube from vinyl tubing by
pulling.
REMOVE CLAMP
AND
PULL DOWN

Manitowoc SM050 Specifications

General

Brand	Manitowoc
Model	SM050
Category	Ice Maker
Language	English
