Mantall XE80C - Page 42

Operator’s Manual
Self-Propelled Scissor Lift
Version1
42
Stowed machine size:
Length
2,42 m
2,45 m
2,45 m
2,45 m
2,45 m
Length with platform extended
3,5 m
3,5 m
3,5 m
3,5 m
3,5 m
Width
1,2 m
1,2 m
1,2 m
1,2 m
1,2 m
Height
2,12 m
2,25 m
2,38 m
2,51 m
2,64 m
Height with platform folded
1,56 m
1,69 m
1,82 m
1,95 m
1,95 m
Wheelbase
1,85 m
1,85 m
1,85 m
1,85 m
1,85 m
Static wheel load
1075 kg
1184 kg
1288 kg
1448 kg
1452 kg
Hydraulic tank capacity
15 L
15 L
25 L
25 L
25 L
Vertical/lateral slope rating
30%
30%
30%
30%
30%
Ground clearance
0,1 m
0,1 m
0,1 m
0,1 m
0,1 m
Ground clearance (pothole guards)
0,019 m
0,019 m
0,019 m
0,019 m
0,019 m
Inside rotation radius
0 m
0 m
0 m
0 m
0 m
Outside rotation radius
2,3 m
2,3 m
2,3 m
2,3 m
2,3 m
Number of people (max.)
2
2
2
2
2
Raising time
32 s
45 s
55 s
72 s
80 s
Lowering time
30 s
30 s
37 s
38 s
46 s
Traction speed
3,4 km/h
3,4 km/h
3,4 km/h
3,4 km/h
3,4 km/h
Safe speed
0,7 km/h
0,7 km/h
0,7 km/h
0,7 km/h
0,7 km/h
Vertical tilt angle
ANSI / CSA Standard
3°
3°
3°
3°
3°
CE / AUS Standard
3°
2°
2°
2°
-
Lateral tilt angle
ANSI / CSA Standard
2°
2°
2°
2°
2°
CE / AUS Standard
2°
1,5°
1,5°
1,5°
-
Power source
4 x 6 V 225 Ah
Tire size
406 x 127 x 318 mm
Drive model
Hydraulic drive or electric drive
