1110. Warning messages
Warning Fault Possible cause Corrective action
02
SOS Emergency signal enabled. Check position of folding leaves.
Check emergency stop button.
03
Obstruction when Closing Obstruction during the
closing cycle.
Check that there are no obstructions during
closure.
04
Outside key switch The key has not be removed
aer 1 min
Remove the key from the outside key switch
device.
05
Parameter error Door parameter fault. Contact Manusa Technical Service.
06
Obstruction when Opening Obstruction during the
opening cycle.
Check that there are no obstructions in the
opening area.
07
Photocell 1 Interior photocell blocked for
more than 1 minute.
Clean the photocells. Should fault persist,
contact Manusa Technical Service.
08
Photocell 2 Exterior photocell blocked for
more than 1 minute.
Clean the photocells. Should fault persist,
contact Manusa Technical Service.
09
Fire Fire alarm signal triggered. Check that it is not a false alarm.
11
Batteries Battery not overly charged. If the door has been disconnected for a while,
connect it and wait 24 hours for the batteries
to charge.
Should fault persist, contact Manusa
Technical Service.
12
Interior Radar Interior radar detection more
than 1 minute.
Contact Manusa Technical Service.
13
Exterior Radar Exterior radar detection more
than 1 minute.
Contact Manusa Technical Service.
15
Auxiliary processor Communications failure with
auxiliary processor.
Should fault persist, contact Manusa
Technical Service.
16
Side safety device Presence detection in the
leaves clear-width area for
more than 1 minute.
Check that there are no objects within the
sensor detection radius.
17
Lock Lock stuck.
Failure on attempting to close
the lock.
Contact Manusa Technical Service.
22
Opening safety fault Opening safety sensors not
detected.
Contact Manusa Technical Service.
23
Closure safety fault Closure safety sensors not
detected.
Contact Manusa Technical Service.
24
Closure safety Closure safety sensor failure. Contact Manusa Technical Service.
33
Current leakage Motor insulation failure. Contact Manusa Technical Service.
34
Power module Power module stoppage due
to overcurrent or insulation
failure.
Contact Manusa Technical Service.
35
Encoder Encoder error.
One of the two channels of
the encoder is faulty.
Contact Manusa Technical Service.
36
Self-adjustment fault Self-adjustment not
completed correctly.
Contact Manusa Technical Service.
49
Critical alarm Possible general failure
of the motor control
microprocessor.
Contact Manusa Technical Service.
10. Warning messages
When the automatic door operator detects a door malfunction, the program switch screen will show a numeric code.
The meaning of the code is summarised in the table below. Depending on the operator, sometimes the code numbers
may be dierent. *
