Nuts & bolts
CE-PLUS 4.2X13
i
Screw end covers to both ends of the cover as
shown in the diagrams.
DET
10.15.1
DET
10.15.2
Fig.
10.15
DET
10.15.2
DET
10.15.1
DET 10.15.2
DET
10.15.1
Fig.
10.15
10.3.4 Side caps assembly.
