Manusa Visio C2H - Page 7

DMJOIC201EN - v2
VISIO C2H OPERATOR - INSTALLATION MANUAL
7
10 mm approx.
i
Keep a distance of 10mm to the right and left of the
main profile.
Fig.
2.5
i
1. Track profile Length = AT-20mm
2. Insulation profile Length = AT-20mm
Fig. 2.4
Fig.
2.5
Fig. 2.4
2.2.2 Position. 2.2.1 Introduce.
2.2 TARCK PROFILE ASSEMBLY
i
Drill hole size Ø9 along main profile as shown in
diagrams.
Fig. 2.2 Fig. 2.1
Tools
Drill bit no.9
Fig. 2.3
Fig. 2.2
Fig. 2.1
Space drill holes
2. PREPARE MAIN PROFILE
2.1 DRILLING
