About the cable labels (supplied) for channel identification
Attach the cable label corresponding to each speaker to each speaker cable.
This makes it easier to connect the speakers to the power amp.
Channel Color
FRONT L White
FRONT R Red
CENTER Green
SURROUND L Light Blue
SURROUND R Blue
SURROUND BACK L Beige
SURROUND BACK R Brown
FRONT HEIGHT L Light Yellow
FRONT HEIGHT R Yellow
TOP FRONT L Light Yellow
TOP FRONT R Yellow
TOP MIDDLE L Light Yellow
TOP MIDDLE R Yellow
TOP REAR L Light Yellow
TOP REAR R Yellow
Channel Color
SURROUND HEIGHT L Light Yellow
SURROUND HEIGHT R Yellow
REAR HEIGHT L Light Yellow
REAR HEIGHT R Yellow
FRONT DOLBY L Light Yellow
FRONT DOLBY R Yellow
SURROUND DOLBY L Light Yellow
SURROUND DOLBY R Yellow
BACK DOLBY L Light Yellow
BACK DOLBY R Yellow
TOP SURROUND Black
SUBWOOFER 1 Black
SUBWOOFER 2 Black
