Example connection when using two sets of Dolby
Atmos Enabled speakers
.
C
SBL
SBR
SW
SL SR
FL
FR
FDL FDR
SDL SDR
0
Set “Height” - “Dolby Sp” to “4ch” in the menu when connecting in this
configuration. (v
p. 219)
.
CHANNEL7
(C)
CHANNEL7
(C)
CHANNEL1
(FL)
CHANNEL2
(FR)
CHANNEL3
(SL)
CHANNEL4
(SR)
CHANNEL1
(FL)
CHANNEL2
(FR)
CHANNEL3
(SL)
CHANNEL4
(SR)
CHANNEL5
(SBL)
CHANNEL6
(SBR)
CHANNEL5
(SBL)
CHANNEL6
(SBR)
CHANNEL1
(FL)
CHANNEL2
(FR)
CHANNEL3
(SL)
CHANNEL4
(SR)
CHANNEL7
(C)
CHANNEL1
(FL)
CHANNEL2
(FR)
CHANNEL3
(SL)
CHANNEL4
(SR)
CHANNEL7
(C)
CHANNEL5
(SBL)
CHANNEL6
(SBR)
CHANNEL5
(SBL)
CHANNEL6
(SBR)
SW SR SL FR FLC
SBLSBR
SDLSDR FDLFDR
BALANCED
BALANCED
UNBALANCED
UNBALANCED
HEIGHT 1
z
HEIGHT 2
z
【
MM8077
】
z
You can change the combination of the HEIGHT1 and HEIGHT2 channels in the
settings. (v
p. 66)
