Combination of height speakers to be used Connected connectors
Number of
height/
ceiling speakers
Number of
Dolby
speakers
Combination pattern
HEIGHT1 RCA
and HEIGHT1
XLR
HEIGHT2 RCA
SUBWOOFER 2
PRE OUT
4 speakers None
Front Height & Surr. Height Front Height Surround Height Subwoofer 2
Front Height & Rear Height
z
Front Height Rear Height Subwoofer 2
5 speakers None
Front Height & Surr. Height & Top Surround Front Height Surround Height Top Surround
Top Front & Rear Height & Top Surround
z
Front Height Rear Height Top Surround
z
For the best Auro-3D experience Surround Height speakers are recommended, however you may substitute Rear Height speakers from a Dolby Atmos speaker setup in
place of Surround Height speakers.
