9.1ch +
Front B:
0
The Pre Amplifier of this unit is assigned to 2 channels
for connecting to the second front speaker.
0
You can switch between the desired combination of
front speakers A and front speakers B. (v p. 240)
Switch the front speaker using the “Front Speaker”
setting. (v p. 240)
Dolby
Atmos :
0
Setting to assign the Pre amplifiers within this unit for
the speaker layout suitable for Dolby Atmos playback.
(v p. 243)
When using the front height, rear height or Dolby Atmos
Enabled speakers for Dolby Atmos playback, set “Assign
Mode” to either “11.1ch” or “9.1ch”.
Upgrade (Auro-3D)
Auro-3D:
0
Setting to assign the power amplifiers with this unit
for the speaker layout suitable for Auro-3D playback.
(v p. 244)
For the best Auro-3D experience surround height
speakers are recommended, however you may
substitute rear height speakers in place of surround
height speakers.
When using the rear height speakers, set “Assign
Mode” to “9.1ch” or “11.1ch”.
o
Detailed settings when “Assign Mode” is set to
“11.1ch”
When “Assign Mode” is set to “11.1ch”, set the following items.
n
Height Speakers
Select the number of the height speakers used in MAIN ZONE.
2 Height Speakers
(Default):
Uses a set of (two) height speakers.
4 Height Speakers : Uses two sets of (four) height speakers.
Using Dolby Speakers :
Select when the Dolby Atmos Enabled
speakers are connected.
Upgrade (Auro-3D)
5 Height Speakers:
Uses five height speakers
z
z
If “5 Height Speakers” is selected, connect the Top Surround speaker to the
Subwoofer 2 terminal.
