Connecting a power amp
0
Connect a power amp (sold separately) to the PRE OUT connector of
this unit.
0
This unit has UNBALANCED RCA PRE OUT connector and
BALANCED XLR PRE OUT connector. Connect to the correct
connector for your power amp. If your power amp has both connectors,
connect to either of them.
0
Connect the speakers to the power amp.
0
For details on speaker connections, see the User Guide for the power
amp.
0
This section shows how to make a 11.1-channel connection.
For how to make other speaker connections, see page
50.
GAV8802 BALANCED XLR PRE OUT connector PIN arrangementH
.
2
1
3
A
GND (Ground)
B
HOT (+)
C
COLD (–)
The PIN arrangement in this device uses the European method.
In the USA method, B is COLD, and C is HOT.
When connecting a device that utilizes the USA type of PIN arrangement,
replace the B and C plugs on one side of the balanced cable.
NOTE
0
Do not short the HOT and GND or COLD and GND for use.
0
Disconnect this unit’s power plug from the power outlet before connecting the
speakers.
Also, turn off the power amp and subwoofer.
