In addition to the connections described in (v p. 53 - 61), this unit allows for
various speaker connections with the “Amp Assign” setting.
Also refer to the menu screen in “View Terminal Config.” on the “Amp Assign” setting
screen, which shows how to make connections in your environment.
.
Back
Speakers/Amp Assign
RCA
Assign Mode
-Height Speakers
-Layout
11.1ch
4 Height Speakers
Top Front & Top Rear
XLR
FRONT SURROUNDCENTER SURR.BACK F.WIDE F.HEIGHT T.REAR
12
SUBWOOFER
FRONT F.WIDE
T.FRONT
SUBWOOFER
CENTER
T.REAR
SURROUND
SURR.BACK
