Marantz CD5005 - Page 69

MAIN
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
C328 nsp CAP, ELECT(10V/100uF) CCEA1AH101T 1
C329 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C330 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC 1
C331 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C332 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC 1
C335 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C336,337 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC 2
C339 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC 1
C341 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C342 nsp CAP, ELECT(16V/220uF) CCEA1CH221T 1
C343 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C344 00MOA33505020 CAP, ELECT(50V/3.3uF) CCEA1HH3R3T 1
C345,346 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 2
C347 nsp CAP, ELECT(16V/220uF) CCEA1CH221T 1
C348 nsp CAP, ELECT(50V/33uF) CCEA1HH330T 1
C349,350 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 2
C351 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC 1
C352 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C353 00MOA107025R1 CAP, ELECT(ROA, 25V/100UF, 10X16) CCEA1EROA101T 1
OTHER PARTS GROUP
CN2101 nsp WAFER , STRAIGHT(3PIN) CJP03GA19ZY 1
CN2201 nsp WAFER , SMD (2MM PITCH)-3P U CJP03GA208ZY 1
CN2801 nsp WAFER, STRAIGHT, 13PIN CJP13GA19ZY 1
CN301 nsp WAFER, FFC(7P-1mm, ANGLE) CJP07GB113ZY 1
CN3101 nsp WAFER , 4P STRAIGHT CJP04GA19ZY 1
CWC100 nsp WAFER , SMD (2MM PITCH) CJP06GA208ZY 1
CWC101 nsp WAFER , SMD (2MM PITCH) CJP05GA208ZY 1
B1,2 nsp PLATE , EARTH(TRONIC ELECTRONICS) CJT1A026 2
BK201 nsp BRACKET , PCB CMD1A569-V1 1
FCC300 nsp WAFER, FFC, SMD(19P-1mm, STRAIGHT) CJP19GA193ZY 1
K100 943623100030D MODULE , OPTICAL(TX 16MHz) CJSJST1124 1
K101 943643102590M JACK, 1P(BK),SEPA-GND,GOLD CJJ4M085Z 1
K300 90M-YT003120R JACK, 2P(ORG), SEPA-GND, SILVER CJJ4N036Z 1
L100 90M-LU000220R INDUCTOR CHIP 10UH (3225 PKG) HLQ10E100KRZ 1
L101-103 nsp FERRITE CHIP BEAD(2012/220R) CLZBLM21PG221SN1 3
L105-107 nsp FERRITE CHIP BEAD(2012/220R) CLZBLM21PG221SN1 3
L2 nsp FERRITE CHIP BEAD(2012/220R) CLZBLM21PG221SN1 1
L252 nsp FERRITE , CHIP BEAD(120ohm, 3216) CLZ91002Z 1
L300,301 nsp FERRITE CHIP BEAD(2012/220R) CLZBLM21PG221SN1 2
L302 nsp FERRITE , CHIP BEAD(120ohm, 3216) CLZ91002Z 1
L303 nsp FERRITE CHIP BEAD(2012/220R) CLZBLM21PG221SN1 1
PFCK10 nsp WAFER, FFC, SMD(16P-1mm, STRAIGHT) CJP16GA193ZY 1
S300 90M-SS000710R SWITCH , SLIDE KSS2B016Z 1
X251 90M-JX001390R X-TAL, 16.934MHz, HC-49/U, 12pF, 30PPM HOX16934A120C 1
X300 943141100750D X-TAL, 10MHz, HC-49/SMD, 12pF COX10000E120S 1
Z1 nsp WIRE ASS'Y(1P, 80MM,BLK,#22) CWE5202080A 1
! 90M-FS001370R FUSE(218Series, 250V/630mA) KBA2C0630TLEY 1
90M-FC500030R FERRITE , RING CLZ9W003Z 1
90M-FC500130R FERRITE , CORE CLZ9Z071Z 1
nsp COVER , SCREW CMD1A495 1
nsp SCREW , DOT CTBD3+8JFB 1
nsp SCREW CTB3+10JFB 5
nsp SCREW CTB3+6FFB 5
nsp SCREW CTB3+6JR 18
nsp SCREW CTB3+8JFB 4
nsp SCREW CTW3+12JR 4
nsp SCREW CTW3+18JR 4
nsp SCREW CTW3+8JR 2
