Marantz CD5005 - Exploded View Parts List

EXPLODED
EXPLODED
※Parts indicated by "nsp"on this table cannot be supplied.
※The
p
arts listed
b
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver gold model
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
30 nsp MAIN PCB ASS'Y COP12662C 1
★ ns
p
FRONT PCB ASS'
Y
COP12663C
┣14
ns
p
FRONT PCB ASS'
Y
COP12663C-4 1
┣15
ns
p
STANDBY PCB ASS'
Y
COP12663C-3 1
┣16
ns
p
PHONE PCB ASS'
Y
COP12663C-5 1
┣29
ns
p
A
UDIO PCB ASS'
Y
COP12663C-2 1
┣31
ns
p
POWER PCB ASS'
Y
COP12663C-1 1
┣32
ns
p
FLASHER PCB ASS'
Y
COP12663C-7 1
┗★ ns
p
TRANS PCB ASS'
Y
COP12663C-6 1
1 421410006004M BADGE , MARANTZ CGB1A206 1
2 943415100410M ORNAMENT, DOOR B CGR1A552ZB37 1
2 943415100400M ORNAMENT, DOOR SG CGR1A552RMZD10 1
3 943416101150M WINDOW, FIP CGU1A423A12Y 1
4 943402104700M PANEL , AL FRONT B CKM1A203WC23 1
4 943402104690M PANEL , AL FRONT SG CKM1A203VC62 1
5 nsp PANEL , SUB CGW1A462B37 1
6 943404100590M PANEL , SIDE(L) U1B, N1B CGW1A463RNVB37 1
6 943402104980M PANEL , SIDE(L) K1B CGW1A463RNUB37 1 *
6 943404100600M PANEL , SIDE(L) N1SG, FN CGW1A463ROVD10 1
6 943402104990M PANEL , SIDE(L) K1SG CGW1A463ROUD10 1 *
7 943402007080M PANEL , SIDE(R) B CGW1A464RNB37 1
7 943402007090M PANEL , SIDE(R) SG CGW1A464ROD10 1
8 nsp SHEET, LED CGX1A411Z 1
9 481510003006M INDICATOR, POWER CGL1A274 1
10 411510015017M KNOB, POWER B CBT1A1072 1
10 411510021036M KNOB, POWER SG CBT1A1072RMD10 1
11 943411102840M KNOB, PLAY B CBT1A1181 2
11 943411102850M KNOB, PLAY SG CBT1A1181RMD10 2
12 943172100160S FIP CFL16ST103GINK 1
13 nsp BRACKET, FIP CHG1A584 2
17 nsp NUT, PHONE CNE1A013 1
18 nsp BRACKET, PHONE CMD1A677-V1 1
19 nsp BURRER,IR,UPPER PCB CHG1A185 1
20 nsp FRAME, FRONT CUF2A004 1
21 nsp CHASSIS, BOTTOM CUA6A289 1
22 00M243W057210 FOOT, FRONT CKL2A042H46 4
23 00M32CW107010 CUSHION, FOOT CHG1A360 4
24 nsp HOLDER, PCB CHE170 4
25 nsp HOLDER, PCB CHE2A030 4
! 26 90M-TS002510R TRANS ASS'Y N, K CLT5M025YE 1
! 26 90M-TS002530R TRANS ASS'Y U
CLT5M025YU
1
! 26 90M-TS002520R TRANS ASS'Y F CLT5M025YJ 1
27 nsp SUPPORT, MECHA CMD2A842 1
28 943302100130D CD MECHA ASS'Y CJDKT690 1
28-1 900302100200S CD MECHANISM (Traverse) -13
28-2 30201005100AD LM BELT
For LOADING MECHA
-13
33 nsp PANEL, REAR U CKF5A390U 1
33 nsp PANEL, REAR N CKF6A390N 1
33 nsp PANEL, REAR K CKF6A390K 1
33 nsp PANEL, REAR F CKF6A390F 1
34 401310003002M CABINET, TOP B CKC2A187K117 1
34 401310003033M CABINET, TOP SG CKC2A187D11 1
35 943411007050M KNOB, LEVEL B CBN1A170B37 1
35 00M24AW154120 KNOB, LEVEL SG CBN1A170RMD10 1
37 nsp COVER, SCREW CMD1A495 1
37 nsp TAPE, HEMELON CHS1A032 5
38 nsp WASHER, GND CNW1A035 1
39 nsp SHEET, SCREW CGX1A439 1
40 00MYJ04002640 RECEPTACLE, AC CJJ8A006ZW 1
42 nsp CUSHION,SHIELD KMC1A264 1
43 nsp SHIELD, CASE FLASHER U CMC1A441 1
44 nsp BURRER CHG1A113 5
S1 nsp SCREW CTB3+6JR 18
S2 nsp SCREW CTB3+6FFB 5
S3 nsp SCREW , DOT CTBD3+8JFB 1
S4 nsp SCREW CTB3+8JFB 23
S5 nsp SCREW CTW3+8JR 6
S6 nsp SCREW B CTW3+8JFZR 6
S6 nsp SCREW SG CTW3+8JFC 6
S7 nsp SCREW CTB3+10JR 14
S8 nsp SCREW CTB3+10JFB 5
S9 nsp SCREW CTW3+12JR 4
S10 nsp SCREW CTW3+18JR 4
S11 nsp SCREW,TRANS CHD2A023R 2
S12 nsp SCREW CTB3+8JR 4
★ 943606007140M CABLE , CARD
(
19P,10MM,250MM,B,8MM
)
CWC4F4A19A250B08 1
★ 943606502280M CABLE , CARD CD Mecha
(
16P, 1mm, 140mm, A TYPE
)
CWC4F1A16A140A10 1
★ ns
p
2P WIRE ASS'Y
(
100MM
)
CWZPM5003TW91A 1
TW91 nsp 2P WIRE ASS'Y(100MM) CWZPM5003TW91 1
7
