2 – Front and rear panel—Audio signal connections
11
ENGLISH
D ERASE button
Performs the same function as the front panel
ERASE/DEL button (
F).
E RECORD button
Performs the same function as the front panel
(record)/TR.INCR. button (
J).
F SYNC REC button
Performs the same function as the front panel
SYNC REC/< button (
K).
G REC MUTE button
Records approximately four seconds of silence.
After the silence is recorded, the CDR633 will
enter record-ready mode (→ p.31).
H SEARCH , buttons
Search through the disc forward ( ) or back-
ward ( ).
I SKIP , buttons
Perform the same function as turning the front
panel MULTI JOG dial (
A).
J STOP button
Performs the same function as the front panel
(stop) button (
G).
K PAUSE button
Performs the same function as the front panel
(pause) button (I).
L PLAY button
Performs the same function as the front panel
(play) button (
H).
Audio signal connections
Input
Only the input jack(s) selected by the front panel
INPUT SELECT (
6
) button will be used.
Choose one of the following three sets of input jacks,
and make the appropriate connections.
•ANALOG IN (UNBALANCED) jacks L/R (M)
•DIGITAL IN (COAXIAL) jack (
O)
•DIGITAL IN (OPTICAL) jack (
P)
The display indicates the currently selected input
jack(s) (
→
p.25).
Output
Signals are output from all of the following three sets
of output jacks. Connect the desired set(s) of output
jacks.
•ANALOG OUT (UNBALANCED) jacks L/R
(
N)
•DIGITAL OUT (COAXIAL) jack (
O)
•DIGITAL OUT (OPTICAL) jack (
P)
