23 24
PRESS <PLAY>
LOAD SBC442 TEST CD (1kHz, -30dB) 4822 397 30155
CHECK:
•
Flex and wire connections
CL11
= 11.2896MHz at pin 2 conn. JJ01
•
•
+5V, +12V, -12V
Kill transistors QN51, QN52, QN53, QN54
•
I
2
S signals at pin 5, pin 6, pin 8 conn. JJ01
•
CHECK:
FILTER_L, FILTER_R
signals : 1kHz, 350mVpp
•
CDR_LEFTOUT, CDR_RIGHTOUT
signals : 1kHz, 320mVpp
•
DAC FILTER_L, DAC FILTER_R circuits (I/O board circuit diagram 5)
KILL
voltage testpoint 1 : -8V during play
MUTE
voltage : low during play
•
•
•
ANALOG OUT PATH OK
Figure 7-17
Troubleshooting analog-out path
7.2.3 Digital in/out paths
7.3 Headphone board
There is a cinch digital-in paths and an optical path taking the
digital signals pretty much straight to the DASP on the CDR
main board. The optical-out and the digital-out path take the
signal from the DASP on the CDR main board to their
respective output connectors on the I/O board.
The L and R analog signals coming from the analog output on
the I/O board pass an adjustable amplifier (opamp Q901) after
which they are passed on to the headphone connector. The
amplification is adjusted by means of a potentiometer
positioned at the front of the CDR player.
