Marantz DR6000 - Page 35

41
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
P916-HEAD PHONE
CIRCUIT BOARD
P916-CAPACITORS
C901
4822 124 41539 ELECT. 47µF M 16V RA-2 OA47601620
C904
C905 4822 124 90354 ELECT. 100µF M 16V RA-2 OA10701620
C906 4822 124 90354 ELECT. 100µF M 16V RA-2 OA10701620
P916-RESISTORS
R901 4822 117 13632 CHIP 100k
Ω ±5% 1/16W NN05104610
R902 4822 117 13632 CHIP 100k
Ω ±5% 1/16W NN05104610
R903 4822 051 30273 CHIP 27k
Ω ±5% 1/16W NN05273610
R904 4822 051 30273 CHIP 27k
Ω ±5% 1/16W NN05273610
R905 4822 051 30123 CHIP 12k
Ω ±5% 1/16W NN05123610
R906 4822 051 30123 CHIP 12k
Ω -+5% 1/16W NN05123610
R907 4822 117 13632 CHIP 100k
Ω ±5% 1/16W NN05104610
R908 4822 117 13632 CHIP 100k
Ω ±5% 1/16W NN05104610
R909
4822 117 12521 CHIP 68 Ω ±5% 1/10W NI05680110
R912
R913
4822 051 30222 CHIP 2.2k Ω ±5% 1/16W NN05222610
R916
R917 4822 116 82487 CHIP 0
Ω ±5% 1/16W NN05000610
R920 9965 000 00602 VAR. 10k
Ω B D-CUT RM01031170
P916-SEMICONDUCTORS
Q901 4822 209 31378 IC NJM4556MB HC10045090
Q903 4822 130 43818 TRS. 2SC2878 A OR BRANK HT328782A0
Q904 4822 130 43818 TRS. 2SC2878 A OR BRANK HT328782A0
P916-MISCELLANEOUS
J901 9965 000 01662 H.P JACK HLJ0540-01-410 BL YJ01003870
L901 4822 157 10416 EMI FILTER BLM11B102S 1608 FN31010030
L902 4822 157 10416 EMI FILTER BLM11B102S 1608 FN31010030
PH16-POWER SW.
CIRCUIT BOARD
PH16-CAPACITORS
C907 5322 126 11578 CER. CHIP 1000pF ±10% B 50V DK96102300
C908 5322 126 11578 CER. CHIP 1000pF ±10% B 50V DK96102300
C910 4822 122 40617 CER. 0.1µF 50V +80 -20% DD38104010
CH05 4822 122 33276 CER. DE7150 F 103M DK17103840
PH16-MISCELLANEOUS
F820 /F FUSE 1A 250V UL/CSA FS10100350
F820 /K, /N 4822 070 31002 FUSE 1A 250V BS LISTED FS10100850
F820 /U FUSE 1A 250V UL/CSA FS10100350
GH05 4822 122 33276 CER. DE7150 F 103M DK17103840
L001 /F MAINS TRANSF.
100V 50/60HZ F
TS15749010
L001 /K MAINS TRANSF. 220/110V K TS15749030
L001 /N 9965 000 05920 MAINS TRANSF.
230V50/60HZ N/K
TS15749020
L001 /U MAINS TRANSF.
120V 60HZ U/C
TS15749040
LH01 9965 000 00394 HR-24R-E273 27MH 0.6A FN01010070
SH01 9965 000 05921 PUSH SWITCH
ESB92S94B TV-5 1.5MM
SP01012480
SH02 /K SLIDE SWITCH
SDKGA4 SEMKO
SS02021510
PP16-MAIN CIRCUIT BOARD
PP16-CAPACITORS
C301 4822 124 41539 ELECT. 47µF M 16V RA-2 OA47601620
C311 4822 122 10172 CER. CHIP 220pF ±10% B 50V DK96221300
C312 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C313 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C314 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C601 FILM 0.0033µF J M 50V DF15332350
C602 FILM 0.0033µF J M 50V DF15332350
C603
FILM 0.001µF J M 50V DF15102350
C606
C629
4822 124 80119 ELECT. 100µF 16V ARA OA10702540
C632
C651 4822 122 10172 CER. CHIP 220pF ±10% B 50V DK96221300
C652 4822 122 10172 CER. CHIP 220pF ±10% B 50V DK96221300
C654 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
C655
4822 124 90365 ELECT. 220µF M 25V RA-2 OA22702520
C658
C701 4822 124 41539 ELECT. 47µF M 16V RA-2 OA47601620
C702 4822 124 41539 ELECT. 47µF M 16V RA-2 OA47601620
C703 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
C704 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
C705 4822 124 90352 ELECT. 10µF M 16V RA-2 OA10601620
C706 4822 124 90352 ELECT. 10µF M 16V RA-2 OA10601620
C707 4822 124 41539 ELECT. 47µF M 16V RA-2 OA47601620
C708 4822 124 41539 ELECT. 47µF M 16V RA-2 OA47601620
C709 4822 124 41539 ELECT. 47µF M 16V RA-2 OA47601620
C710 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C711
4822 124 12404 ELECT. 220µF M 16V RA-2 OA22701620
C714
C715 FILM 0.0015µF J M 50V DF15152350
C716 FILM 0.0015µF J M 50V DF15152350
C717 4822 122 10172 CER. CHIP 220pF ±10% B 50V DK96221300
C718 4822 122 10172 CER. CHIP 220pF ±10% B 50V DK96221300
C719 4822 124 41539 ELECT. 47µF M 16V RA-2 OA47601620
C720 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C721 4822 124 41539 ELECT. 47µF M 16V RA-2 OA47601620
C722 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C723 4822 124 80067 ELECT. 4.7µF M 50V RA-2 OA47505020
C724 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C725 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C726 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C727 4822 124 41539 ELECT. 47µF M 16V RA-2 OA47601620
C728 4822 124 41539 ELECT. 47µF M 16V RA-2 OA47601620
C729 4822 124 41539 ELECT. 47µF M 16V RA-2 OA47601620
C730 4822 126 11687 CER. CHIP 0.1µF DK98104200
C731 4822 122 40617 CER. 50V DC 0.1µF +80% -20% DD38104010
C803 9965 000 05917 ELECT. 1000µF 35V SILMIC OA10803540
C804 9965 000 05917 ELECT. 1000µF 35V SILMIC OA10803540
C807 4822 124 12404 ELECT. 220µF M 16V RA-2 OA22701620
C808 4822 124 12404 ELECT. 220µF M 16V RA-2 OA22701620
C809 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
C810 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
C811 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
C812 4822 124 12404 ELECT. 220µF M 16V RA-2 OA22701620
C813 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
C815 4822 124 90354 ELECT. 100µF 16V RA-2 OA10701620
C816 4822 124 90354 ELECT. 100µF 16V RA-2 OA10701620
C817 4822 124 22703 ELECT. 0.22µF M 50V RA-2 OA22405020
C818 4822 124 22703 ELECT. 0.22µF M 50V RA-2 OA22405020
C819 4822 124 22703 ELECT. 0.22µF M 50V RA-2 OA22405020
C821 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
C822 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
C823 4822 124 90356 ELECT. 1000µF M 35V RA-2 OA10803520
C824 4822 124 11583 ELECT. 2200µF 35V RA-2 OA22803520
C825 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
C826 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
C827 4822 124 12404 ELECT. 220µF M 16V RA-2 OA22701620
C828 4822 124 12404 ELECT. 220µF M 16V RA-2 OA22701620
C829 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
C830 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
C841 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
