44
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
QH07
4822 130 63928 CHIP TRS. 2SA1312 B HX113121B0
QH10
QH11 4822 130 61355 CHIP TRS. 2SC2712 O.Y HX327122A0
QH12 4822 130 61355 CHIP TRS. 2SC2712 O.Y HX327122A0
QH13 5322 130 41844 F.E.T. 2SK170 V LANK HF201701H0
QH14 5322 130 41844 F.E.T. 2SK170 V LANK HF201701H0
QH15 4822 130 62649 F.E.T. 2SJ74 V LANK HF100741H0
QH16 4822 130 62649 F.E.T. 2SJ74 V LANK HF100741H0
QN01 4822 130 61355 CHIP TRS. 2SC2712 O.Y HX327122A0
QN02 4822 130 61355 CHIP TRS. 2SC2712 O.Y HX327122A0
QN03 4822 130 61355 CHIP TRS. 2SC2712 O.Y HX327122A0
QN04 4822 130 61311 CHIP TRS. 2SA1162 O.Y HX111622A0
QN05 4822 130 61355 CHIP TRS. 2SC2712 O.Y HX327122A0
QN06 4822 130 61311 CHIP TRS. 2SA1162 O.Y HX111622A0
QN51
4822 130 43818 TRS. 2SC2878 A OR BRANK HT328782A0
QN54
QY05 4822 130 61355 CHIP TRS. 2SC2712 O.Y HX327122A0
PP16-MISCELLANEOUS
F802 /F,/U FUSE 0.5A 125V UL/CSA FS20050220
F802 /K, /N 4822 071 55001 FUSE 0.5A 250V SEMKO VDE FS20050200
F804 /F,/U FUSE 0.5A 150V UL/CSA FS20050220
F804 /K, /N 4822 071 55001 FUSE 0.5A 250V SEMKO VDE FS20050200
F821 /F,/U FUSE 0.8A 125V UL/CSA FS20080220
F821 /K, /N 9965 000 05918 FUSE 0.8A 250V SEMKO VDE FS20080200
F823 /F,/U FUSE 0.8A 125V UL/CSA FS20080220
F823 /K, /N 9965 000 05918 FUSE 0.8A 250V SEMKO VDE FS20080200
F841 /F,/U FUSE 0.4A 125V UL/CSA FS20040220
F841 /K, /N 9965 000 05919 FUSE 0.4A 250V SEMKO VDE FS20040200
F843 /F,/U FUSE 2.0A 125V UL/CSA FS20200220
F843 /K, /N 4822 071 52002 FUSE 2.0A 250V SEMKO VDE FS20200200
J301 4822 218 11487 OPTICAL RECIVER GP1F32R YJ15000150
J311 4822 290 81638 TERMINAL 14X14 RA 1L1P YT02010790
J651 4822 290 61216 TERMINAL 2P RCA W/R GOLD YT02020950
J701 4822 290 61216 TERMINAL 2P RCA W/R GOLD YT02020950
JF51 4822 267 41009 TERMINAL 2P RCA PIN JACK YT02020890
JJ01 9965 000 05911 FFC CONNECTER 30P 0.5MM YJ07021230
JT01 4822 290 81638 TERMINAL 14X14 RA 1L1P YT02010790
JT02 4822 267 31369 OPTICAL OUTPUT GP1F32T YJ15000090
L311 4822 157 10416 EMI FILTER
BLM11B 102S 1608
FN31010030
L651 4822 157 10416 EMI FILTER
BLM11B 102S 1608
FN31010030
L652 4822 157 10416 EMI FILTER
BLM11B 102S 1608
FN31010030
L701 4822 157 10416 EMI FILTER
BLM11B 102S 1608
FN31010030
L702 4822 157 10416 EMI FILTER
BLM11B 102S 1608
FN31010030
LF51 4822 157 10416 EMI FILTER
BLM11B 102S 1608
FN31010030
LT01 4822 157 10416 EMI FILTER
BLM11B 102S 1608
FN31010030
LT02 4822 142 60422 PULSE TRANSF.
TPS247MN-0386AN
TP41042030
SF51 4822 277 21559 SLIDE SWITCH INT/EXT SS02021150
PY16-FRONT CIRCUIT BOARD
PY16-CAPACITORS
CY03 5322 122 32654 CER. CHIP 0.022µF ±10% XTR DK96223200
CY04 9965 000 05913 CER. CHIP 22pF ±2% 50V DD942203A0
CY05 9965 000 05913 CER. CHIP 22pF ±2% 50V DD942203A0
CY06 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
CY07 4822 124 21901 ELECT. 47µF 6.3V EJ47600610
CY09 4822 122 31765 CER. CHIP 100pF ±5% CG 50V DD95101300
CY10 4822 122 31765 CER. CHIP 00pF ±5% CG 50V DD95101300
CY11 4822 126 11687 CER. CHIP 0.1µF DK98104200
CY12 4822 126 11704 CER. CHIP 0.022µF 50V DK98223300
CY13 4822 124 21901 ELECT. 47µF 6.3V EJ47600610
PY16-RESISTORS
RY01 4822 117 12925 CHIP 47k
Ω ±5% 1/16W NN05473610
RY02 4822 117 12925 CHIP 47k
Ω ±5% 1/16W NN05473610
RY03 4822 117 12925 CHIP 47k
Ω ±5% 1/16W NN05473610
RY04 4822 051 30101 CHIP 100
Ω ±5% 1/16W NN05101610
RY05 4822 051 30393 CHIP 39k
Ω ±5% 1/16W NN05393610
RY06 4822 051 30471 CHIP 470
Ω ±5% 1/16W NN05471610
RY09 4822 051 30101 CHIP 100
Ω ±5% 1/16W NN05101610
RY10 4822 051 30101 CHIP 100
Ω ±5% 1/16W NN05101610
RY11 4822 051 30472 CHIP 4.7k
Ω ±5% 1/16W NN05472610
RY12 4822 051 30103 CHIP 10k
Ω ±5% 1/16W NN05103610
RY13 4822 051 30103 CHIP 10k
Ω ±5% 1/16W NN05103610
RY14 4822 051 30153 CHIP 15k
Ω ±5% 1/16W NN05153610
RY15 4822 051 30153 CHIP 15k
Ω ±5% 1/16W NN05153610
RY21
4822 051 30472 CHIP 4.7k Ω ±5% 1/16W NN05472610
RY26
RY27 4822 117 12925 CHIP 47k
Ω M ±5% 1/16W NN05473610
PY16-SEMICONDUCTORS
DY04 5322 130 31504 ZENER DIODE MTZ J 3.3A HD30331000
QY01 IC TMP87PM74ZF OTP U-COM HC60015050
QY02 4822 130 61355 CHIP TRS. 2SC2712 O.Y HX327122A0
QY03 4822 130 61355 CHIP TRS. 2SC2712 O.Y HX327122A0
QY04 4822 130 61355 CHIP TRS. 2SC2712 O.Y HX327122A0
PY16-MISCELLANEOUS
SY01
9965 000 00373 TACT SW MATU EVQ11L05R SP01013370
SY08
SY12 9965 000 00373 TACT SW MATU EVQ11L05R SP01013370
SY13 9965 000 00373 TACT SW MATU EVQ11L05R SP01013370
SY17 9965 000 00373 TACT SW MATU EVQ11L05R SP01013370
SY18 9965 000 00373 TACT SW MATU EVQ11L05R SP01013370
SY22 9965 000 00373 TACT SW MATU EVQ11L05R SP01013370
SY23 9965 000 00373 TACT SW MATU EVQ1105R SP01013370
SY26 9965 000 05915 ROTARY SWITCH EC11B ROT
ENCODER WITH PUSH SW
SR03030030
VX01 9965 000 05916 DISPLAY UNIT FTD BJ727GNK
15GRID X 22ANODE
HQ31208410
XY01 4822 242 72066 SERAMIC VIB. 8.0MHz
CST8.0MHZ MT
FQ08004010
ZY01 4822 130 11494 PHOTO UNIT RPM6936-V4
IR SENSOR
HW10004210
PY26-STAND BY
CIRCUIT BOARD
DY01 4822 130 80326 L.E.D. LT3D8B RED 3O HI10062320
